Timing Belt Pulley T45 With 8mm Pilot Bore
Part. N° 28.0614
| APPLICATIONS |
| - Timing belt reverse unit for LR12 45mm rails & slides |
| - Re bore & key 8mm pilot to inch or metric size up to Ø16mm |
| - Use as idler pulley |
| - Medium duty linear motion |
| - Use adaptor plate for mounting NEMA 23, NEMA 34 & NEMA 42 motors & gearboxes |
| TECHN. DATA / ITEMS SUPPLIED |
| - Aluminum housing, clear anodized |
| - 32AT10 aluminum pulley, 19 teeth, Precision 8mm Bore |
| - Qty 2, Steel Ball Bearings |
| - Zinc plated fastening hardware |
| - Bore Dia. |
- 8 mm No key |
| - Re borable to: |
- 16 mm |
| - Travel (1 Rev) |
- 190 mm |
| - Frictional moment at 1/1000 belt tensioning |
- .35 Nm |
| - Max load |
- 70 Nm |
| - Weight |
- 1.27 Kg. |
