M8x14 Set Screw
Cone Point
Part. N° 21.1303
CAD DOWNLOAD ► 3D STEP | Solidworks 2013 | Inventor 2012
APPLICATIONS | |
---|---|
- Used to fasten T-slot Bar Profile, Part # 21.1030 to 45 series profiles | |
- Closest inch screw | 5/16-18 |
- Ø8mm = | .315 inches |
- Length 14 mm = | .551 inches |
TECHN. DATA / ITEMS SUPPLIED | |
---|---|
- Steel, zinc plated | |
- Din | 914 |
- Diameter | 8 mm |
- Length | 14 mm |
- Thread pitch | 1.25 mm |
- Hex drive | 4 mm |
- End type | Cone Point |
ASSEMBLY |
---|
- Screw thru M8x1.25 tapped hole in t-slot bar until set screw bottoms out on profile & drives t-slot bar up |
