Adaptor Flange 45
Part. N° 21.2300
CAD DOWNLOAD ► 3D STEP | | Inventor 2026
| APPLICATIONS |
|---|
| - Internal Bracket for lagging to floor |
| - Mounting of leveling feet or casters to inside of cart or frame |
| TECHN. DATA / ITEMS SUPPLIED | |
|---|---|
| - Steel, powder coated gray | |
| - Qty 4, M8x18 SHCS | |
| - Qty 4 M8 Square Nuts With Position Fixing | |
| - Leveling pads sold separately | |
| - Weight | - .311 kg |
| ASSEMBLY |
|---|
| - Mount to profile t-slots with supplied hardware |
| - An additional nut must be ordered for MiniTec Leveling pads or casters |
