1/4-20 Square Econo-Nut
Part. N° 21.9041
| APPLICATIONS |
| - Economical alternative to position fixing nuts |
| - Does not stay in position when used in vertical t-slots & can be harder to catch in horizontal t-slots than position fixing nuts. |
| |
| TECHN. DATA / ITEMS SUPPLIED |
| - Steel, Zinc Plated |
| - Threaded 1/4-20 UNC, Class 2B |
| - Grade 5 |
| - Weight |
- .003kg |
| ASSEMBLY |
| - Press in thru side of t-slot or slide in from ends on 45 series profiles |
| -Slide in from the end only for 30 series profiles |
| - Select longest screw that doesn't bottom out in t-slot |
| - Tighten screw thru part & into nut |
| - For 1/8" thick parts use 16mm long screw |
| - For 1/4" thick parts use 20mm long screw |
