Module LR6 Z 90

PART N^o 28.0501

PART N^o: 28.0501 each

Linear scanning & positioning applications
Speeds up to 3M/S
Maximum Torque 30 Nm (22 Ft-Lb)
Pick & place

PART No: 28.0501 Category: Linear System LR6 Z

Technical Data / Items Supplied

See itemized list for included components
Motor & motor mounting sold seperately
Travel length to 3.8 meters(150″)
Click here for load capacity
Repeatability +/- .25mm(.01″)

Applications

Assembly Info

Unit Ships Fully Assembled

28.0501_LR6_Z_90_L

28.0501_LR6_Z_90_M

Downloads
