Mounting Bracket 45

PART No 21.1411
$51.70 each
PART No: 21.1411$51.70 each
  • End to end or end to face connections
  • Removeable attachments
  • Convenient for mounting profiles to existing frames
PART No: 21.1411 Category:

Technical Data / Items Supplied

  • 2 cast aluminum blocks, material GD-ZnAl4Cu1 , Powercoated gray
  • 2 anti-rotation devices
  • 2 M8x16 socket head cap screws
  • 1 M8 x 35 socket head cap screw
  • 2 M8 square nuts
  • 1 M8 hex nut
  • Weight – .426 kg

Applications

Assembly Info

  • Both halves are the same
  • Form tap profile center hole M8 for end connection
  • Attach to square nut in t-slot for side connections
  • Recommended locking torque 20 Nm
