Base Plate 30×60 M8

PART No 21.2114
$15.84 each
PART No: 21.2114$15.84 each
PART No: 21.2114 Category:

Technical Data / Items Supplied

  • Cast aluminum, powder coated gray
  • Qty 2, M8x25 Screws
  • Hole Threaded M8x1.25 Thru
  • Weight – .084 kg

Applications

Assembly Info

  • Thread profile end M8 using Forming Tap, Part # 26.1082
  • Alternatively, order the profile threaded using Part # 25.1087
  • Insert supplied M8x25 screws thru holes in plates & tighten into threaded holes of profile
Base_Plate_30x60_Main_Page
21.2114_BASE_PLATE_30X60_M8_L
21.2114_BASE_PLATE_30X60_M8_M
21.2114_BASE_PLATE_30X60_M8_R

Downloads

3D Step
Solidworks
Inventor
