Hinge 19 AL

PART No 21.1100
$20.90 each
PART No: 21.1100$20.90 each
  • Hinged doors made from 19 & 32 series profiles
  • Mounting panels together at various angles
PART No: 21.1100 Category:

Technical Data / Items Supplied

  • 2 Aluminum hinge blocks, clear anodized
  • 4 M8x18 socket head cap screws
  • 4 M8 square nuts
  • 1 Hinge pin
  • 4 Rectangular screw caps gray
  • 2 Pin end caps gray
  • Weight -.111kg
  • Load max. – 400N

Applications

Assembly Info

  • Alignment tab on back of hinge ensures alignment of door & frame
  • Orientation 1: lift removable
  • Orientation 2: non lift removable
21.1100_Hinge_19_M
21.1100_Hinge_19_L
21.1100_Hinge_19_M
21.1100_Hinge_19_R

Downloads

3D Step
Solidworks
Inventor
