M8 Gray Plastic Leveler 45mm Base

PART No 21.1871
$12.65 each
PART No: 21.1871$12.65 each
  • Leveling foot for machine bases, machine frames & machine guard
PART No: 21.1871 Category:

Technical Data / Items Supplied

  • Threaded M8 steel stud, zinc plated
  • Polyamide plastic base, gray
  • hard NBR rubber anti-skid pad, black
  • Steel jamb nut, zinc plated
  • Thread pitch – 1.25 mm
  • Stud swivel max. – 15°
  • Suggested Design Height – 45 mm (1.75″)
  • Load max – 500 kg

Applications

Assembly Info

  • Thread center bore of profile M8x1.25 using M8 Forming Tap, Part # 26.1082
  • Thread stud into profile & level frame using 14mm crescent wrench
  • Once leveled tighten jamb nut against profile using 13mm crescent wrench
MP_21.1871_M8_Plastic_Lev_45mm
21.1871_M8_Plastic_Lev_45mm_L
21.1871_M8_Plastic_Lev_45mm_M
21.1871_M8_Plastic_Lev_45mm_R
Leveler 15 Deg Angle

Downloads

3D Step
Solidworks
Inventor
