Base Plate 45×90 M16

PART No 21.1040
$15.95 each
PART No: 21.1040$15.95 each
  • Attach M16 leveler to end of 45×90 profile
PART No: 21.1040 Category:

Technical Data / Items Supplied

  • Cast aluminum, powder coated gray
  • Qty 2 M8x22 SHCS
  • Thread Dia. – 16 mm
  • Thread Pitch – 2 mm
  • Weight – .160 kg

Applications

Assembly Info

  • Tap both holes on end of 45×90 using M8 Forming Tap, Part # 26.1082
  • Insert supplied M8x22 screws thru holes in plate and tighten to profile
MP_21.1040_B_T_Plate_45x90_M16
21.1040_B_T_Plate_45x90_M16_L
21.1040_B_T_Plate_45x90_M16_M
21.1040_B_T_Plate_45x90_M16_R
