M16 Black Plastic Leveler W/Lag Holes

PART No 21.1141
$58.30 each
PART No: 21.1141$58.30 each
  • Leveling of machine frames,custom tables, work benches, etc. that need to be lag bolted to the floor.
PART No: 21.1141 Categories ,

Technical Data / Items Supplied

  • Threaded M16 steel stud, zinc plated
  • Polyamide plastic base, black
  • Anti skid pad sold separately, Part # 21.1075/2
  • Steel jamb nut, zinc plated
  • Thread pitch – 2 mm
  • Stud swivel max. – 15°
  • Suggested design Height – 75 mm (3″)
  • Load max – 1800 kg

Applications

Assembly Info

MP21.1141_M16_FT_BRS_BLK
21.1141_M16_FT_BRS_BLK_L
21.1141_M16_FT_BRS_BLK_M
21.1141_M16_FT_BRS_BLK_R

Downloads

3D Step
Solidworks
Inventor
