Connecting Plate 90 x 32

PART No 21.1346
$15.73 each
PART No: 21.1346$15.73 each
  • Connection of panels where gaps are not permissable
  • Joining of large wall sections. Use to make large enclosures easy to dis-assemble and re-assemble
  • Strengthen profile joints
  • Can be mounted after assembly is complete
PART No: 21.1346 Category:

Technical Data / Items Supplied

  • Cast aluminum plate, powdercoated gray
  • 2 M8x22 socket head cap screws
  • 2 M8 square nuts with position fixing
  • Weight – .170 kg

Applications

Assembly Info

  • Press square nuts into profiles
  • Recommended locking torque 20 Nm
21.1346_Connecting_Plate_90x32_MP
21.1346_Connecting_Plate_90x32_L
21.1346_Connecting_Plate_90x32_M
21.1346_Connecting_Plate_90x32_R

Downloads

3D Step
Solidworks
Inventor
